Maximum Ratings
Parameter Rating Unit
Supply Voltage -0.6 to +10 V
Supply Current 100 mA
Power Dissipation 600 mW
Operating Temperature Range -40 to +85 °C
Storage Temperature Range -40 to 150 °C
Electrical Characteristics
Measured at T
AMB
= 25°C, V
CC
= 3.3V (Note 1), R
CAL1
= R
CAL2
= 36K (setting I
D1/2/4/5
to 10mA),
R CALM = 68K (setting I D3/6 to 5mA) unless otherwise stated
Parameter Conditions Symbol Min. Typ. Max. Unit
Operating Voltage Range V
CC
3.0 8.0 V
Supply Current
I
D1-6
= 0 I
CC
1.6 4.0 mA
I
D1-6
= 10mA, no R
CALM
I
CC(L)
62 64 mA
Substrate Voltage
I
CSUB
= 0 V
CSUB
-3.0 -2.65 -2.0 V
I
CSUB
= -200uA V
CSUB(L)
-2.55 -2.0 V
Oscillator Frequency F
OSC
150 260 600 kHz
Gate Characteristics
Gate (G1 to G6, resistor R
CALM
not present)
Current Range I
G
-100 +500 uA
Voltage Low I
D
= 12mA, I
G
= -10uA V
G(L)
-3.0 -2.5 -2.0 V
Voltage High I
D
= 8mA, I
G
= 0 V
G(H)
0 0.7 1.0 V
Voltage Disabled (*1)
I
D
= 0, I
G
= -10uA,
V
RCAL1-2
= 3.0V
V
G(DIS)
-3.0 -2.5 -2.0 V
Gate (G3 and G6, resistor R
CALM
present)
Current Range I
G
-100 +500 uA
Voltage Low I
D
= 6mA, I
G
= -10uA V
G(L)
-3.0 -2.5 -2.0 V
Voltage High I
D
= 4mA, I
G
= 0 V
G(H)
0 0.7 1.0 V
Voltage Disabled
(*1)
I
D
= 0, I
G
= -10uA,
V
RCAL2
= V
RCALM
3.0V
V
G(DIS)
-3.0 -2.5 -2.0 V
Drain Characteristics
Drain (D1 to D6, resistor R
CAL
M not present)
Current Range I
D
0 15 mA
Current Operating
Standard Application
Circuit
I
D(OP)
8 10 12 mA
Current Disabled (*1) V
D
= 0, V
RCAL
= 3.0V I
D(DIS)
10 uA
Voltage Operating I
D
= 10mA V
D(OP)
1.8 2.0 2.2 V
