ZLNB2013
ISSUE 1 - AUGUST 2005
2
ABSOLUTE MAXIMUM RATINGS
Supply voltage -0.6V to 12V
Supply current 500mA
V POL1 and V POL2
Input voltage 25V Continous
Operating temperature -40 to 80°C
Storage temperature -40 to 85°C
Power dissipation (T
amb 25 C)
QSOP16 500mW
SYMBOL PARAMETER CONDITIONS LIMITS UNIT
S
Min. Typ. Max.
V
CC
Supply voltage 5 8 V
I
CC
Supply current HOR1,2= BHOR1,2= TD1,2= BTD1, 2= 0mA
V
POL
1= V
POL
2= Don’t Care
F
IN
1= F
IN
2= Don’t Care
9 12 mA
V
POL1
and V
POL2
Inputs
I
POL
V
TPOL
V
TENA
T
SPOL
Current
Threshold voltage
Enable threshold
voltage
Switching speed
V
POL1
= V
POL2
= 25V (Note 2)
T
amb
=-40°C to 80°C
T
amb
=-40°C to 80°C
100
14
8.0
200
14.75
9.0
240
15.5
10.0
100
␮A
V
V
␮S
HOR
OUT
1 and HOR
OUT
2 outputs
VHOR
HIGH
VHOR
LOW
Voltage high
Voltage low
IHOR
OUT
1,2=-100 ␮A,V
POL
1,2=15.5V
IHOR
OUT
1,2=5mA,V
POL
1,2=14V
V
CC
-1.0
0
V
CC
0.7
0.30
V
CC
0.5
V
V
BHOR
OUT
1 and BHOR
OUT
2 outputs
VBHOR
HIG
H
VBHOR
LOW
Voltage high
Voltage low
IBHOR
OUT
1,2=-100 ␮A,V
POL
1,2=14.0V
IBHOR
OUT
1,2=5mA,V
POL
1,2=15.5V
V CC -1.0
0
V CC 0.7
0.30
V CC
0.5
V
V
Enable 1,2 outputs
VEN
HIGH
VEN
LOW
Voltage high
Voltage low
IEnable 1,2=-100 ␮A,V
POL
1,2=10V
IEnable 1,2=5mA,V
POL
1,2=8.0V
V
CC
-1.0
0
V
CC
0.7
0.30
V
CC
0.5
V
V
Filter amplifier
V
OUT
Bias voltage 3 I
fin
=0 1.75 1.95 2.15 V
F
inz
Input impedance V
FIN
=100mV p/p 150 ⍀
AG Amplifier gain V
FIN
=100mV p/p 30 V/mA
FV
T
V Threshold 3
100 170 350 mV
p/p
ELECTRICAL CHARACTERISTICS TEST CONDITIONS (Unless otherwise stated):
T
amb
= 25ЊC, V
CC
=5V
Note:
1) The parameters Filter Amplifier VOUT, IOUT, Rectifier VOUT and Comparator Threshold Voltage are all directly
(linearly) related to Vcc.
2) Applied via 2.2k resistors
3) These parameters are linear related to VCC
