ZLNB254
Dual DiSEqC™ Interface IC
SUMMARY
The ZLNB254 is a dual channel DiSEqC™ interface for Satellite Low Noise Blocks
(LNB’s) and distribution systems. Providing two accurate DiSEqC™ detectors the
ZLNB254 converts the DiSEqC™ signals into logic level representations enabling
reliable and easy detection for a microprocessor. Packaged in a small footprint
DFN and only requiring two external components per channel the complete solution
is cost effective and requires minimal PCB space.
FEATURES
•
Dual Channel DiSEqC™ interface
•
Reliable and accurate detectors
•
High channel isolation
•
Compatible with Eutelsat and US specifications
•
Simple and easy to design in.
•
Outputs compatible with LSTTL and CMOS loads
•
Operates over a wide supply voltage
• Temperature
compensated
APPLICATIONS
•
DiSEqC™ controlled LNB’s
•
Satellite distribution systems
•
Mono Block LNB’s
• DiSEqC
Actuators
• Set-Top
Boxes
•
Satellite Test Equipment
•
AC satellite control signal detection
