ZTLV431
Issue 7 - April 2008 2 www.zetex.com
© Zetex Semiconductors plc 2008
Absolute maximum ratings
Operation above the absolute maximum rating may cause device failure. Operation at the
absolute maximum ratings, for extended periods, may reduce device reliability.
Unless otherwise stated voltages specified are relative to the ANODE pin.
Package thermal data
Recommended operating conditions
Cathode voltage (V
KA
) 10V
Continuous cathode current (I
KA
) -20 to 20mA
Reference input current range (I
REF
) -0.05 to 3mA
Operating junction temperature -40 to 150°C
Storage temperature -55 to 150°C
Package
⍜
JA
P
DIS
T
A
=25°C
SOT23 380°C/W 330 mW
SOT23F 160°C/W 780 mW
Min. Max. Units
V
KA
cathode voltage V
REF
10 V
I
KA
cathode current 0.1 15 mA
T
A
operating ambient temperature range -40 125 °C
