TL072
LOW NOISE JFET INPUT OPERATIONAL
AMPLIFIERS
TL072 Rev. 1 9 of 11 JULY 2009
www.diodes.com © Diodes Incorporated
Test Circuit
R
L
=2kΩ C
L
=100pF
V
OUT
R
L
C
L
=100pF
V
OUT
10kΩ
1kΩ
Figure 1. Unity-Gain Amplifier Figure 2. Gain-of-10 Inverting Amplifier
Marking Information
(1) SOP-8L
( Top View )
TL072
YY WW X X
Logo
Part Number
5 8
4 1
WW : Week : 01~52; 52
YY : Year : 08, 09,10~
G : Green
X : Internal Code
represents 52 and 53 week
