TL072
LOW NOISE JFET INPUT OPERATIONAL
AMPLIFIERS
TL072 Rev. 1
1 of 11 MAY 2009
©
Diodes Incorporated
• Low
Power
Consumption
•
Wide Common-Mode and Differential Voltage Ranges
•
Low Input Bias and Offset Currents
• Output
Short-Circuit
Protection
•
Low Total Harmonic Distortion…0.003% Typ
•
Low Noise Vn=
ΗΖ
18nV
Typ at f=1kHz
•
High Input Impedance…JFET-Input Stage
• Internal
Frequency
Compensation
• Latch-Up-Free
Operation
• High
Slew
Rate…13V/
μs Typ
•
Common-Mode Input Voltage Range Includes V
CC
+
•
SOP-8L: Available in “Green” Molding Compound
(No Br, Sb)
•
Lead Free Finish/ RoHS Compliant (Note 1)
The JFET-input operational amplifiers in the TL072 are similar to
the TL082, with low input bias and offset currents and fast slew
rate. The low harmonic distortion and low noise make the TL072
ideally suited for high-fidelity and audio preamplifier applications.
Each amplifier features JFET inputs (for high input impedance)
coupled with bipolar output stages integrated on a single
monolithic chip.
•
Active filters
•
Audio pre-amps
TL 072 S G - 13
Package
Packing
S : SOP-8L
Green
13 : Tape & Reel
G : Green
Device
Package
Code
Packaging
(Note 2)
13” Tape and Reel
Quantity
Part Number Suffix
TL072SG-13 S SOP-8L
2500/Tape
&
Reel
-13
Notes: 1. EU Directive 2002/95/EC (RoHS). All applicable RoHS exemptions applied. Please visit our website at
2. Pad layout as shown on Diodes Inc. suggested pad layout document AP02001, which can be found on our website at
Features
General Description
Applications
Ordering Information
