Zxbm1015 – Diodes ZXBM1015 User Manual
Page 10
ZXBM1015
10
ISSUE 3 - MAY 2007
Europe
Zetex GmbH
Kustermann-Park
Balanstraße 59
D-81541 München
Germany
Telefon: (49) 89 45 49 49 0
Fax: (49) 89 45 49 49 49
[email protected]
Americas
Zetex Inc
700 Veterans Memorial Hwy
Hauppauge, NY 11788
USA
Telephone: (1) 631 360 2222
Fax: (1) 631 360 8222
[email protected]
Asia Pacific
Zetex (Asia) Ltd
3701-04 Metroplaza Tower 1
Hing Fong Road, Kwai Fong
Hong Kong
Telephone: (852) 26100 611
Fax: (852) 24250 494
[email protected]
Corporate Headquarters
Zetex Semiconductors plc
Zetex Technology Park
Chadderton, Oldham, OL9 9LL
United Kingdom
Telephone (44) 161 622 4444
Fax: (44) 161 622 4446
[email protected]
© Zetex Semiconductors plc 2007
DIM
Millimeters
Inches
DIM
Millimeters
Inches
Min
Max
Min
Max
Min
Max
Min
Max
A
-
1.20
-
0.047
L
0.45
0.75
0.018
0.030
A1
0.05
0.15
0.002
0.006
e
0.65 BSC
0.026 BSC
A2
0.80
1.05
0.031
0.041
b
0.19
0.30
0.007
0.012
D
6.4
6.6
0.252
0.260
c
0.09
0.20
0.004
0.008
E
6.40 BSC
0.252 BSC
⍜
0°
8°
0°
8°
E1
4.3
4.5
0.169
0.177
-
-
-
-
-
PACKAGE DIMENSIONS
Controlling dimensions are in millimeters, approximate dimensions are given inches.
Conforms to JEDEC MO-153 AC
PACKAGE OUTLINE - TSSOP20
