ZXMS6002G
Issue 3 - June 2007 7 www.zetex.com
© Zetex Semiconductors plc 2007
Status flag
Normal operation V
STATUS
4.95 V V
IN
= 5V
Current limit operating V
STATUS
2.5 V V
IN
= 5V
Thermal shutdown activated V
STATUS
0.2 1 V V
IN
= 5V
Normal operation V
STATUS
8.0 V V
IN
= 10V
Current limit operation V
STATUS
3.0 V V
IN
= 10V
Thermal shutdown activated V
STATUS
0.35 1 V V
IN
= 10V
Inverse diode
Source drain voltage V
SD
1 V V
IN
=0V, -I
D
=1.4A,
NOTES:
(*) Protection features may operate outside spec for V
IN
<4.5V.
(†) The drain current is limited to a reduced value when Vds exceeds a safe level
(‡) Integrated protection functions are designed to prevent IC destruction under fault conditions described in the
datasheet. Fault conditions are considered as "outside" normal operating range. Protection functions are not designed
for continuous, repetitive operation.
Electrical characteristics (at T
amb
= 25°C unless otherwise stated)
Parameter Symbol Min. Typ. Max. Unit Conditions
