ZXMD63C03X
ISSUE 2 - SEPTEMBER 2007
12
Europe
Zetex GmbH
Kustermannpark
Balanstraße 59
D-81541 München
Germany
Telefon: (49) 89 45 49 49 0
Fax: (49) 89 45 49 49 49
[email protected]
Americas
Zetex Inc
700 Veterans Memorial Hwy
Hauppauge, NY 11788
USA
Telephone: (1) 631 360 2222
Fax: (1) 631 360 8222
[email protected]
Asia Pacific
Zetex (Asia) Ltd
3701-04 Metroplaza Tower 1
Hing Fong Road, Kwai Fong
Hong Kong
Telephone: (852) 26100 611
Fax: (852) 24250 494
[email protected]
Corporate Headquarters
Zetex Semiconductors plc
Zetex Technology Park
Chadderton, Oldham, OL9 9LL
United Kingdom
Telephone (44) 161 622 4444
Fax: (44) 161 622 4446
[email protected]
© Zetex Semiconductors plc 2007
e
c
E
E1
D
b
A1
A
A2
R1
R
L
PACKAGE DIMENSIONS
1.02
0.040
4.8
0.189
0.41
0.016
0.65
0.023
mm
inches
PAD LAYOUT DETAILS
DIM
Millimeters
Inches
Min.
Max.
Min.
Max.
A
-
1.10
-
0.0433
A1
0.05
0.15
0.002
0.006
A2
0.75
0.95
0.0295
0.0374
b
0.25
0.40
0.010
0.0157
c
0.13
0.23
0.005
0.009
D
2.90
3.10
0.114
0.122
E
4.90 BSC
0.193 BSC
E1
2.90
3.10
0.114
0.122
e
0.65 BSC
0.025 BSC
L
0.40
0.70
0.0157
0.0192
R
0.07
-
0.0027
-
R1
0.07
-
0.0027
-
