Maximum Ratings
(@T
A
= +25°C, unless otherwise specified.)
Characteristic
Symbol
Value
Unit
Drain-Source voltage
V
DSS
-60
V
Gate-Source voltage
V
GS
20
V
Continuous Drain current
V
GS
= 10V
(Note 7)
I
D
-3.0
A
T
A
= +70°C (Note 7)
-2.4
(Note 6)
-2.3
Pulsed Drain current
V
GS
= 10V
(Note 8)
I
DM
-13.6
A
Continuous Source current (Body diode)
(Note 7)
I
S
-2.5
A
Pulsed Source current (Body diode)
(Note 8)
I
SM
-13.6
A
Thermal Characteristics
(@T
A
= +25°C, unless otherwise specified.)
Characteristic
Symbol
Value
Unit
Power dissipation
Linear derating factor
(Note 6)
P
D
1.1
8.8
W
mW/
C
(Note 7)
1.92
15.4
Thermal Resistance, Junction to Ambient
(Note 6)
R
θJA
113
C/W
(Note 7)
65
Operating and storage temperature range
T
J
, T
STG
-55 to +150
C
Notes:
6. For a device surface mounted on 25mm x 25mm x 1.6mm FR4 PCB with high coverage of single sided 1oz copper, in still air conditions; the device is
measured when operating in a steady-state condition.
7. Same as note (6), except the device is measured at t
5 sec.
8. Same as note (6), except the device is pulsed with D = 0.02 and pulse width 300µs. The pulse current is limited by the maximum junction temperature.
