ZXMP6A17G
Maximum Ratings
(@T
A
= +25°C, unless otherwise specified.)
Characteristic Symbol
Value
Unit
Drain-Source Voltage
V
DSS
-60 V
Gate-Source Voltage
V
GS
±20
V
Continuous Drain Current
V
GS
= 10V
(Note 6)
I
D
-4.3
A
T
A
= +70°C (Note 6)
-3.5
(Note 5)
-3.0
Pulsed Drain Current
V
GS
= 10V
(Note 7)
I
DM
-13.7 A
Continuous Source Current (Body Diode)
(Note 6)
I
S
-4.8 A
Pulsed Source Current (Body Diode)
(Note 7)
I
SM
-13.7 A
Thermal Characteristics
(@T
A
= +25°C, unless otherwise specified.)
Characteristic Symbol
Value
Unit
Power Dissipation
Linear Derating Factor
(Note 5)
P
D
2.0
16
W
mW/°C
(Note 6)
3.9
31
Thermal Resistance, Junction to Ambient
(Note 5)
R
θJA
62.5
°C/W
(Note 6)
32.0
Thermal Resistance, Junction to Lead
(Note 8)
R
θJL
9.8
Operating and Storage Temperature Range
T
J
, T
STG
-55 to +150
°C
Notes:
5. For a device surface mounted on 25mm x 25mm x 1.6mm FR4 PCB with high coverage of single sided 1oz copper, in still air conditions; the device is
measured when operating in a steady-state condition.
6. Same as note (5), except the device is measured at t
≤ 10sec.
7. Same as note (5), except the device is pulsed with D = 0.02 and pulse width 300µs. The pulse current is limited by the maximum junction temperature.
8. Thermal resistance from junction to solder-point (at the end of the drain lead).
