Electrical Characteristics
(@T
A
= +25°C, unless otherwise specified.)
Characteristic Symbol
Min
Typ
Max
Unit
Test
Condition
OFF CHARACTERISTICS
Drain-Source Breakdown Voltage
BV
DSS
-60
V
I
D
= -250µA, V
GS
= 0V
Zero Gate Voltage Drain Current
I
DSS
-0.5 µA
V
DS
= -60V, V
GS
= 0V
Gate-Source Leakage
I
GSS
100
nA
V
GS
=
20V, V
DS
= 0V
ON CHARACTERISTICS
Gate Threshold Voltage
V
GS(th)
-1.0
V
I
D
= -250µA, V
DS
= V
GS
Static Drain-Source On-Resistance (Note 12)
R
DS(ON)
0.125
Ω
V
GS
= -10V, I
D
= -2.3A
0.190
V
GS
= -4.5V, I
D
= -1.9A
Forward Transconductance (Notes 12 & 13)
g
fs
4.7
S
V
DS
= -15V, I
D
= -2.3A
Diode Forward Voltage (Note 12)
V
SD
-0.85 -0.95 V I
S
= -2.0A, V
GS
= 0V
Reverse recovery time (Note 13)
t
rr
25.1
ns
I
S
= -1.7A, di/dt = 100A/µs
Reverse recovery charge (Note 13)
Q
rr
27.2
nC
DYNAMIC CHARACTERISTICS (Note 13)
Input Capacitance
C
iss
637
pF
V
DS
= -30V, V
GS
= 0V
f = 1MHz
Output Capacitance
C
oss
70
pF
Reverse Transfer Capacitance
C
rss
53
pF
Total Gate Charge (Note 14)
Q
g
9.0
nC
V
GS
= -4.5V
V
DS
= -30V
I
D
= -2.2A
Total Gate Charge (Note 14)
Q
g
17.7
nC
V
GS
= -10V
Gate-Source Charge (Note 14)
Q
gs
1.6
nC
Gate-Drain Charge (Note 14)
Q
gd
4.4
nC
Turn-On Delay Time (Note 14)
t
D(on)
2.6
ns
V
DD
= -30V, V
GS
= -10V
I
D
= -1A, R
G
6.0Ω
Turn-On Rise Time (Note 14)
t
r
3.4
ns
Turn-Off Delay Time (Note 14)
t
D(off)
26.2
ns
Turn-Off Fall Time (Note 14)
t
f
11.3
ns
Notes:
12. Measured under pulsed conditions. Pulse width
300µs; duty cycle 2%
13. For design aid only, not subject to production testing.
14. Switching characteristics are independent of operating junction temperatures.
