DRAIN-SOURCE DIODE CHARACTERISTICS
PARAMETER SYMBOL MIN. TYP MAX. UNIT CONDITIONS.
Diode Forward Voltage (1) V SD -
- 0.79
0.89 -
- V
V I S =0.32A, V GS =0V
I
S
=1.0A, V
GS
=0V
Reverse Recovery Time
(to I
R
=10%)
T RR - 135 ns I F =0.45A, V GS =0V,
I
R
=100mA, V
R
=10V
(1) Measured under pulsed conditions. Width=300 µ s. Duty cycle ≤ 2% (2) Sample test.
(3) Switching times measured with 50 Ω source impedance and <5ns rise time on a pulse generator
Spice parameter data is available upon request for this device
ZVN4210G
