ZXMN4A06G
Document number: DS33545 Rev. 3 - 2
2 of 7
January 2014
© Diodes Incorporated
ZXMN4A06G
ADVANCED INFORMATION
Maximum Ratings
(@T
A
= +25°C, unless otherwise specified.)
Characteristic Symbol
Value
Unit
Drain-Source Voltage
V
DSS
40 V
Gate-Source Voltage
V
GS
20
V
Continuous Drain Current
V
GS
= 10V
(Note 6)
I
D
7
A
T
A
= +70°C (Note 6)
5.6
(Note 5)
5
Pulsed Drain Current
V
GS
= 10V
(Note 7)
I
DM
22 A
Continuous Source Current (Body diode)
(Note 6)
I
S
5.4 A
Pulsed Source Current (Body diode)
(Note 7)
I
SM
22 A
Thermal Characteristics
(@T
A
= +25°C, unless otherwise specified.)
Characteristic Symbol
Value
Unit
Power Dissipation
Linear Derating Factor
(Note 5)
P
D
2
16
W
mW/°C
(Note 6)
3.9
31
Thermal Resistance, Junction to Ambient
(Note 7)
R
θJA
62.5
°C/W
(Note 6)
32.2
Operating and Storage Temperature Range
T
J
, T
STG
-55 to +150
°C
Notes:
5. For a device surface mounted on 25mm x 25mm FR-4 PCB with high coverage of single sided 1oz copper, in still air conditions.
6. For a device surface mounted on FR-4 PCB measured at t
≦
5 secs.
7. Repetitive rating 25mm x 25mm FR4 PCB, D = 0.05, pulse width 10μs - pulse width limited by maximum junction temperature.
Thermal Characteristics
