SOT223 N-CHANNEL ENHANCEMENT

MODE VERTICAL DMOS FET

ISSUE 1 - APRIL 1998

FEATURES

*

BV

DSS

=60V

*

R

DS(ON)

= 0.33

*

Repetitive Avalanche Rating

APPLICATIONS

*

DC - DC Converters

*

Solenoids/Relay Drivers for Automotive

*

Stepper Motor Drivers

PARTMARKING DETAIL -

ZVN4306V

ABSOLUTE MAXIMUM RATINGS.

PARAMETER

SYMBOL

VALUE

UNIT

Drain-Source Voltage

V

DS

60

V

Continuous Drain Current at T

amb

=25°C

I

D

2.1

A

Pulsed Drain Current

I

DM

15

A

Gate Source Voltage

V

GS

±

20

V

Power Dissipation at T

amb

=25°C

P

tot

3

W

Avalanche Current-Repetitive

I

AR

1

A

Avalanche Energy-Repetitive

E

AR

25

mJ

Operating and Storage Temperature Range

T

j

:T

stg

-55 to +150

°C

ZVN4306GV

D

D

S

G
