ZXMN2A14F
S E M I C O N D U C T O R S
ISSUE 3 - SEPTEMBER 2007
2
PARAMETER SYMBOL VALUE UNIT
Junction to Ambient (a) R ⍜JA 125 °C/W
Junction to Ambient
(b)
R ⍜JA 82 °C/W
NOTES
(a) For a device surface mounted on 25mm x 25mm FR4 PCB with high coverage of single sided 1oz copper, in still air conditions.
(b) For a device surface mounted on FR4 PCB measured at t Յ 5 sec.
(c) Repetitive rating - 25mm x 25mm FR4 PCB, D=0.02, pulse width 300 ␮s - pulse width limited by maximum junction temperature.
THERMAL RESISTANCE
PARAMETER SYMBOL LIMIT UNIT
Drain-Source Voltage V
DSS
20 V
Gate-Source Voltage V
GS
Ϯ12 V
Continuous Drain Current @ V
GS
=4.5V; T
A
=25°C (b)
@ V
GS
=4.5V; T
A
=70°C (b)
@ V
GS
=4.5V; T
A
=25°C
(a)
I
D
4.1
3.3
3.4
A
A
A
Pulsed Drain Current
(c)
I
DM
19 A
Continuous Source Current (Body Diode)
(b)
I
S
1.7 A
Pulsed Source Current (Body Diode)
(c)
I
SM
19 A
Power Dissipation at T
A
=25°C
(a)
Linear Derating Factor
P
D
1
8
W
mW/°C
Power Dissipation at T
A
=25°C (b)
Linear Derating Factor
P
D
1.5
12
W
mW/°C
Operating and Storage Temperature Range T
j
, T
stg
-55 to +150 °C
ABSOLUTE MAXIMUM RATINGS
