UMC5N
Document number: DS31205 Rev. 4 - 2
4 of 5
www.diodes.com
November 2011
© Diodes Incorporated
UMC5N
0.1
1
10
0.01 0.1 1 10
-I , OUTPUT CURRENT (mA)
Fig. 7 Typical Input Off Voltage vs. Output Current
(Q2, PNP)
O
T = -55°C
A
T = 25°C
A
T = 85°C
A
T = 150°C
A
V = -5V
CC
0.1
1
10
-I , OUTPUT CURRENT (mA)
Fig. 8 Typical Input ON Voltage vs. Output Current
(Q2, PNP)
O
T = -55°C
A
T = 25°C
A
T = 85°C
A
T = 150°C
A
V = -0.3V
O
Package Outline Dimensions
Suggested Pad Layout
SOT353
Dim Min Max
A 0.10 0.30
B 1.15 1.35
C 2.00 2.20
D 0.65 Typ
F 0.40 0.45
H 1.80 2.20
J 0 0.10
K 0.90 1.00
L 0.25 0.40
M 0.10 0.22
α 0° 8°
All Dimensions in mm
Dimensions Value (in mm)
Z 2.5
G 1.3
X 0.42
Y 0.6
C1 1.9
C2 0.65
A
M
J
L D
B C
H
K
F
X
Z
Y
C1
C2 C2
G
