ZXT790AK
S E M I C O N D U C T O R S
ISSUE 1 - JUNE 2003
2
PARAMETER
SYMBOL
LIMIT
UNIT
Collector-Base Voltage
BV
CBO
-50
V
Collector-Emitter Voltage
BV
CEO
-40
V
Emitter-Base Voltage
BV
EBO
-5
V
Continuous Collector Current
I
C
-3
A
Peak Pulse Current
I
CM
-6
A
Base Current
I
B
-0.5
A
Power Dissipation at TA =25°C
(a)
Linear Derating Factor
Thermal Resistance Junction to Ambient
P
D
2.1
16.8
59
W
mW/°C
°C/W
Power Dissipation at TA =25°C
(b)
Linear Derating Factor
Thermal Resistance Junction to Ambient
P
D
3.0
24.4
41
W
mW/°C
°C/W
Power Dissipation at TA =25°C
(c)
Linear Derating Factor
Thermal Resistance Junction to Ambient
P
D
3.9
30.9
32
W
mW/°C
°C/W
Operating and Storage Temperature Range
T
j
, T
stg
-55 to 150
°C
NOTES
(a)
For a device surface mounted on 25mm x 25mm FR4 PCB with high coverage of single sided 1oz copper, in still
air conditions.
(b)
For a device surface mounted on 50mm x 50mm FR4 PCB with high coverage of single sided 1oz copper in still
air conditions.
(c)
For a device surface mounted on 50mm x 50mm FR4 PCB with high coverage of single sided 2oz copper in still
air conditions.
ABSOLUTE MAXIMUM RATINGS
