ZXT690BK
Absolute Maximum Ratings
(@T
A
= +25°C, unless otherwise specified.)
Characteristic Symbol Value Unit
Collector-Base Voltage BV
CBO
60 V
Collector-Emitter Voltage BV
CEO
45 V
Emitter-Base Voltage BV
EBO
7 V
Continuous Collector Current I
C
3 A
Peak Pulse Current I
CM
6 A
Base Current I
B
0.5 A
Thermal Characteristics
(@T
A
= +25°C, unless otherwise specified.)
Characteristic Symbol Value Unit
Power Dissipation
(Note 6)
P
D
4.0
W
(Note 7) 3.4
(Note 8) 2.1
(Note 9) 1.6
Thermal Resistance, Junction to Ambient Air
(Note 6)
R
θJA
32
°C/W
(Note 7) 36
(Note 8) 59
(Note 9) 80
Thermal Resistance, Junction to Leads (Note 10) R
θJL
3
Thermal Resistance, Junction to Case (Note 11) R
θJC
14.6
Operating and Storage Temperature Range T
J
, T
STG
-55 to +150 °C
ESD Ratings
(Note 12)
Characteristic Symbol Value Unit JEDEC Class
Electrostatic Discharge - Human Body Model ESD HBM 4,000 V 3A
Electrostatic Discharge - Machine Model ESD MM 400 V C
Notes: 6. For a device mounted with the exposed collector pad on 50mm x 50mm 2oz copper that is on a single-sided 1.6mm FR4 PCB; device is measured
under still air conditions whilst operating in a steady-state.
7. Same as note (6), except mounted on 25mm x 25mm 2oz copper.
8. Same as note (6), except mounted on 25mm x 25mm 1oz copper.
9. Same as note (6), except mounted on minimum recommended pad (MRP) layout.
10. Thermal resistance from junction to solder-point (on the exposed collector pad).
11. Thermal resistance from junction to the top of the case.
12. Refer to JEDEC specification JESD22-A114 and JESD22-A115.
