ELECTRICAL CHARACTERISTICS (at T
amb
= 25°C unless otherwise stated).
PARAMETER SYMBOL MIN. TYP. MAX. UNIT CONDITIONS.
Collector-Base
Breakdown Voltage V
(BR)CBO
-40 V I
C
=-100
µ
A
Collector-Emitter
Breakdown Voltage V
(BR)CEO
-40 V I
C
= -10mA*
Emitter-Base
Breakdown Voltage V
(BR)EBO
-5 V I
E
= -100
µ
A
Collector Cut-Off
Current I
CBO
-10 nA V
CB
=-35V
Emitter Cut-Off
Current I
EBO
-10 nA V
EB
=-4V
Collector Emitter
Cut-Off Current I
CES
-10 nA V
CES
=-35V
Collector-Emitter
Saturation Voltage V
CE(sat)
-50
-90
-140
-180 -65
-120
-200
-250 mV
mV
mV
mV I
C
= -0.1A, I
B
= -10mA*
I
C
= -0.25A, I
B
=-20mA*
I
C
= -0.5A, I
B
=-50mA*
I
C
= -0.75A, I
B
=-100mA*
Base-Emitter
Saturation Voltage V
BE(sat)
-1000 -1100 mV I
C
= -0.75A, I
B
= -100mA*
Base-Emitter
Turn-On Voltage V
BE(on)
-890 -1100 mV I
C
= -0.75A, V
CE
= -2V*
Static Forward
Current Transfer
Ratio h
FE
300
300
90
40
20 510
450
190
60
30 I
C
= -10mA, V
CE
=-2V*
I
C
= -0.1A, V
CE
= -2V*
I
C
= -0.5A, V
CE
=-2V*
I
C
= -0.75A, V
CE
= -2V*
I
C
= -1A, V
CE
= -2V*
Transition
Frequency f
T
220 MHz I
C
= -50mA, V
CE
=-10V
f= 100MHz
Output Capacitance C
obo
8 pF V
CB
= -10V, f=1MHz
Turn-On Time t
(on)
75 ns V
CC
= -10V, I
C
=-0.75A
I
B1
=I
B2
=-100mA
Turn-Off Time t
(off)
315 ns
*Measured under pulsed conditions. Pulse width=300
µ
s. Duty cycle
≤
2%
ZUMT720
