Diodes ZUMT718 - Manual (Page 2)

ELECTRICAL CHARACTERISTICS (at T
amb
= 25°C unless otherwise stated).
PARAMETER SYMBOL MIN. TYP. MAX. UNIT CONDITIONS.
Collector-Base
Breakdown Voltage V
(BR)CBO
-20 V I
C
= -100 A
Collector-Emitter
Breakdown Voltage V
(BR)CEO
-20 V I
C
= -10mA*
Emitter-Base
Breakdown Voltage V
(BR)EBO
-5 V I
E
= -100 A
Collector Cut-Off
Current I
CBO
-10 nA V
CB
=-15V
Emitter Cut-Off
Current I
EBO
-10 nA V
EB
=-4V
Collector Emitter
Cut-Off Current I
CES
-10 nA V
CES
=-15V
Collector-Emitter
Saturation Voltage V
CE(sat)
-33.5
-80
-130
-180 -45
-110
-175
-250 mV
mV
mV
mV I
C
= -0.1A, I
B
= -10mA*
I
C
= -0.25A, I
B
= -10mA*
I
C
= -0.5A, I
B
=-20 mA*
I
C
= -1A, I
B
= -100mA*
Base-Emitter
Saturation Voltage V
BE(sat)
-970 -1100 mV I
C
= -1A, I
B
= -100mA*
Base-Emitter
Turn-On Voltage V
BE(on)
-850 -1100 mV I
C
= -1A, V
CE
= 2V*
Static Forward
Current Transfer
Ratio h
FE
300
300
200
100
20 490
450
315
160
75 I
C
= -10mA, V
CE
=-2V*
I
C
= -0.1A, V
CE
= -2V*
I
C
= -0.5A, V
CE
=-2V*
I
C
= -1A, V
CE
= -2V*
I
C
= -1.5A, V
CE
= -2V*
Transition
Frequency f
T
210 MHz I
C
=-50mA, V
CE
=-10V
f=100MHz
Output Capacitance C
obo
11 pF V
CB
=-10V, f=1MHz
Turn-On Time t
(on)
60 ns V
CC
= -10V, I
C
= -1A
I
B1
=I
B2
=-100mA
Turn-Off Time t
(off)
135 ns
*Measured under pulsed conditions. Pulse width=300 s. Duty cycle 2%
ZUMT718
38
