SDM02U30LP3
Document number: DS35774 Rev. 4 - 2
2 of 4
www.diodes.com
October 2013
© Diodes Incorporated
SDM02U30LP3
ADVAN
CE I
N
F
O
RM
ATI
O
N
Maximum Ratings
(@T
A
= +25°C, unless otherwise specified.)
Characteristic Symbol Value Unit
Peak Repetitive Reverse Voltage
Working Peak Reverse Voltage
DC Blocking Voltage V RRM
V RWM
V
R
30 V
RMS Reverse Voltage V R(RMS) 21 V
Average Rectified Output Current I
O
100 mA
Non-Repetitive Peak Forward Surge Current
(8.33ms Half-Sine Waveform)
I
FSM
500 mA
Thermal Characteristics
Characteristic Symbol Value Unit
Power Dissipation (Note 5) P
D
250 mW
Thermal Resistance Junction to Ambient Air (Note 5) R JA 500 °C/W
Operating and Storage Temperature Range T
J
, T
STG
-65 to +150 °C
Electrical Characteristics
(@T A = +25°C, unless otherwise specified.)
Characteristic Symbol Min Typ Max Unit Test Condition
Forward Voltage V F
  0.37
V
I
F
= 10mA
 0.20 
I
F
= 10mA; T
A
= +125°C
Leakage Current (Note 5) I
R
  7
µA
V
R
= 10V
 4 
V R = 30V
Notes: 5. Part mounted on FR-4 PC board with recommended pad layout, which can be found on our website at http://www.diodes.com.
6. Short duration pulse test used to minimize self-heating effect.
0.1
0.2
0.3
0 0.1 0.2 0.3
0
I AVERAGE FORWARD CURRENT (A)
Figure 1 Forward Power Dissipation
F(AV)
P
,
P
O
WE
R
DISS
IP
A
T
IO
N
(W
)
D
Note 5
0 0.1 0.2 0.3 0.4 0.5 0.6 0.7
Figure 2 Typical Forward Characteristics
V , INSTANTANEOUS FORWARD VOLTAGE (V)
F
0.01
0.1
1
10
100
I
, INS
T
AN
T
AN
E
O
U
S
F
O
R
WA
R
D
C
U
R
R
EN
T
(mA
)
F
T = 25°C
A
T = 85°C
A
T = 125°C
A
T = 150°C
A
T = -55°C
A
