SD101AWS – SD101CWS
Document number: DS30078 Rev. 12 - 2
2 of 4
January 2012
© Diodes Incorporated
SD101AWS – SD101CWS
Maximum Ratings
@T
A
= 25°C unless otherwise specified
Characteristic
Symbol
SD101AWS SD101BWS SD101CWS Unit
Peak Repetitive Reverse Voltage
Working Peak Reverse Voltage
DC Blocking Voltage
V
RRM
V
RWM
V
R
60 50 40
V
RMS Reverse Voltage
V
R(RMS)
42 35 28
V
Forward Continuous Current (Note 4)
I
FM
15 mA
Non-Repetitive Peak Forward Surge Current @ t
≤ 1.0s
@ t = 10
μs
I
FSM
50
2.0
mA
Thermal Characteristics
Characteristic Symbol
Value Unit
Power Dissipation (Note 4)
P
D
200 mW
Thermal Resistance, Junction to Ambient Air (Note 4)
R
θJA
625
°C/W
Operating and Storage Temperature Range
T
J,
T
STG
-65 to +125
°C
Electrical Characteristics
@T
A
= 25°C unless otherwise specified
Characteristic Symbol
Min
Typ
Max
Unit
Test
Conditions
Reverse Breakdown Voltage (Note 5)
SD101AWS
V
(BR)R
60
⎯
⎯
V
I
R
= 10
μA
SD101BWS 50
⎯
⎯
I
R
= 10
μA
SD101CWS 40
⎯
⎯
I
R
= 10
μA
Forward Voltage Drop
SD101AWS
V
FM
⎯
⎯
0.41
V
I
F
= 1.0mA
SD101BWS
⎯
⎯
0.40
I
F
= 1.0mA
SD101CWS
⎯
⎯
0.39
I
F
= 1.0mA
SD101AWS
⎯
⎯
1.00
I
F
= 15mA
SD101BWS
⎯
⎯
0.95
I
F
= 15mA
SD101CWS
⎯
⎯
0.90
I
F
= 15mA
Peak Reverse Current (Note 5)
SD101AWS
I
RM
⎯
⎯
200
nA
V
R
= 50V
SD101BWS
⎯
⎯
200
V
R
= 40V
SD101CWS
⎯
⎯
200
V
R
= 30V
Total Capacitance
SD101AWS
C
T
⎯
⎯
2.0
pF
V
R
= 0V, f = 1.0MHz
SD101BWS
⎯
⎯
2.1
V
R
= 0V, f = 1.0MHz
SD101CWS
⎯
⎯
2.2
V
R
= 0V, f = 1.0MHz
Reverse Recovery Time
t
rr
⎯
⎯
1.0 ns
I
F
= I
R
= 5.0mA,
I
rr
= 0.1 x I
R
, R
L
= 100
Ω
Notes: 4. Part mounted on FR-4 PC board with recommended pad layout, which can be found on our website at
5. Short duration pulse test used to minimize self-heating effect.
