DS30760 Rev. 2 - 2 2 of 4 PDU620
PowerDI is a trademark of Diodes Incorporated. www.diodes.com
NEW
P
RODUCT
I
,
INST
ANT
A
NEOUS
FOR
W
A
RD
CURRENT
(A)
F
V , INSTANTANEOUS FORWARD VOLTAGE (V)
Fig. 1 Typical Forward Characteristics
F
1m
10m
100m
1
10
100
0 0.4 0.8 1.2 0.2 0.6 1 1.4
T = -65°C
j
T = 175°C
j
T = 150°C
j
T = 125°C
j
T = 85°C
j
T = 25°C
j
0 40 80 120 200
V , INSTANTANEOUS REVERSE VOLTAGE (V)
Fig. 2 Typical Reverse Characteristics
R
160
0.1
1
10
100
1,000
0.001
0.01
T = 175°C
j
T = -65°C
j
T = 25°C
j
T = 150°C
j
T = 85°C
j
T = 125°C
j
C,
T
O
T
A
L
C
AP
ACIT
ANCE
(pF)
T
V , REVERSE VOLTAGE (V)
Fig. 3 Typical Total Capacitance vs. Reverse Voltage
R
0
50
100
150
200
250
300
350
400
0 10 20 30
f = 1MHz
0
1.5
3
4.5
7.5
6
0 25 50 75 125 100 150 175
I,
D
C
F
O
R
W
ARD
CURRENT
(A)
F
T , AMBIENT TEMPERATURE (°C)
Fig. 4 DC Forward Current Derating
A
Note 3
Note 2
Note 4
Electrical Characteristics @ T
A
= 25 °C unless otherwise specified
Characteristic Symbol Value Unit Test Condition
Minimum Reverse Breakdown Voltage (Note 5) V
(BR)R 200 V I
R
= 5 mA
Maximum Forward Voltage V FM
0.940
0.860
0.975
0.895
V
I
F
= 6A, T
S
= 25 °C
I
F
= 6A, T
S
= 150 °C
I
F
= 8A, T
S
= 25 °C
I
F
= 8A, T
S
= 150 °C
Maximum Reverse Leakage Current (Note 5) I
RM
5
500
mA T
S
= 25 °C, V
R
= 200V
T
S
= 100 °C, V
R
= 200V
Maximum Reverse Recovery Time t
rr 25 ns
I
F
= 0.5A, I
R
= 1.0A
I
RR
= 0.25A (See figure 7)
Notes: 5. Short duration test pulse used to minimize self-heating effect.
