PDU620
6A ULTRA-FAST RECOVERY RECTIFIER
PowerDI
ä
5
Features
Single phase, half wave, 60Hz, resistive or inductive load.
For capacitive load, derate current by 20%.
Mechanical Data
Characteristic
Symbol
Value
Unit
Peak Repetitive Reverse Voltage
Working Peak Reverse Voltage
DC Blocking Voltage
V
RRM
V
RWM
V
R
200
V
RMS Reverse Voltage
V
R(RMS)
141
V
Average Rectified Output Current (See also figure 4)
I
O
6
A
Non-Repetitive Peak Forward Surge Current
8.3ms Single half sine-wave Superimposed on Rated Load
I
FSM
150
A
NEW
P
RODUCT
Maximum Ratings
@ T
A
= 25
°C unless otherwise specified
Characteristic
Symbol
Typ
Max
Unit
Thermal Resistance Junction to Soldering Point
R
qJS
¾
1.5
°C/W
Thermal Resistance Junction to Ambient Air (Note 2) T
A
= 25
°C
R
qJA
95
¾
°C/W
Thermal Resistance Junction to Ambient Air (Note 3) T
A
= 25
°C
R
qJA
60
¾
°C/W
Thermal Resistance Junction to Ambient Air (Note 4) T
A
= 25
°C
R
qJA
40
¾
°C/W
Operating Temperature Range
T
j
-65 to +175
°C
Storage Temperature Range
T
STG
-65 to +175
°C
4. Polymide PCB, 2 oz. Copper. Cathode pad dimensions 9.4mm x 7.2mm. Anode pad dimensions 2.7mm x 1.6mm.
Thermal Characteristics
·
Case: PowerDI
ä
5
·
Case Material: Molded Plastic, “Green” Molding
Compound. UL Flammability Classification Rating 94V-0
·
Moisture sensitivity: Level 1 per J-STD-020C
·
Terminals: Finish – Matte Tin annealed over Copper
leadframe. Solderable per MIL-STD-202, Method 208
·
Polarity: See Diagram on Page 4
·
Marking: See Page 3
·
Weight: 0.096 grams (approx.)
·
Glass Passivated Die Construction
·
Ultra-Fast Recovery Time for High Efficiency
·
High Maximum Junction Temperature
·
High Forward Surge Current Capability
·
For Use in Low Voltage, High Frequency Inverters, Free
Wheeling, and Polarity Protection Applications
·
Lead Free Finish, RoHS Compliant (Note 1)
·
"Green" Molding Compound (No Br, Sb)
·
Qualified to AEC-Q101 Standards for High Reliability
TOP VIEW
BOTTOM VIEW
