ZLLS1000
Electrical Characteristics
(@T
A
= +25°C, unless otherwise specified.)
Characteristic Symbol Min Typ Max Unit Test Condition
Reverse breakdown voltage V
(BR)R
40 - - V I
R
= 500µA
Forward voltage (Note 6) V
F
-
320 355
mV
I F = 50mA
335 380 I
F
= 100mA
380 425 I
F
= 250mA
410 460 I F = 500mA
440 510 I
F
= 750mA
470 560 I
F
= 1A
530 660 I
F
= 1.5A
430 - I
F
= 1000mA, T
A
= +100°C
Reverse current I
R
-
5
500
20
-
μA
μA V
R
= 30V
V
R
= 30V, T
A
= +85°C
Diode capacitance C
D
- 28 - pF f = 1MHz, V
R
= 30V
Reverse recovery time
Reverse recovery charge t
rr
Q
rr
-
5
350
-
ns
nC
Switched from I
F
= 500mA to V
R
= 5.5V
Measured @ I
R
50mA. di /dt = 500mA/ ns.
R
source
= 6 Ω; R
load
= 10 Ω
Notes: 6. Measured under pulsed conditions. Pulse width = 300 μs. Duty cycle < 2%
