SBR30M100
Document number: DS30985 Rev. 7 - 2
2 of 5
www.diodes.com
July 2012
© Diodes Incorporated
SBR30M100CT
SBR30M100CTFP
SBR is a registered trademark of Diodes Incorporated.
Maximum Ratings (Per Leg)
(@T A = +25°C, unless otherwise specified.)
Single phase, half wave, 60Hz, resistive or inductive load.
For capacitance load, derate current by 20%.
Characteristic Symbol Value Unit
Peak Repetitive Reverse Voltage
Working Peak Reverse Voltage
DC Blocking Voltage V
RRM
V
RWM
V
RM
100 V
Average Rectified Output Current Per Device (Per Leg)
(Total)
I O
15
30
A
Non-Repetitive Peak Forward Surge Current 8.3ms
Single Half Sine-Wave Superimposed on Rated Load
I FSM
250 A
Peak Repetitive Reverse Surge Current (2µS-1Khz) I RRM
3 A
Isolation Voltage (ITO-220AB Only)
From terminal to heatsink t = 3 sec.
V
AC
2000 V
Thermal Characteristics (Per Leg)
Characteristic Symbol Value Unit
Typical Thermal Resistance
Package = TO-220AB
Package = ITO-220AB
R θJC 2
4 °C/W
Operating and Storage Temperature Range T J , T STG
-65 to +175 °C
Electrical Characteristics (Per Leg)
(@T
A
= +25°C, unless otherwise specified.)
Characteristic Symbol Min Typ Max Unit Test Condition
Forward Voltage Drop V
F
— — 0.85
V
I
F
= 15A, T
J
= +25°C
— 0.68 0.73 I
F
= 15A, T
J
= +125°C
— — 0.96 I
F
= 30A, T
J
= +25°C
Leakage Current (Note 6) I
R
— — 12 µA V
R
= 100V, T
J
= +25°C
— — 3 mA V
R
= 100V, T
J
= +125°C
Notes: 6. Short duration pulse test used to minimize self-heating effect.
