SBR is a registered trademark of Diodes Incorporated.
SBR3060CTB
Document number: DS31955 Rev. 3 - 2
2 of 4
March 2014
© Diodes Incorporated
SBR3060CTB
ADVAN
CE I
N
F
O
RM
ATI
O
N
Maximum Ratings (Per Leg)
@T
A
= 25°C unless otherwise specified
Single phase, half wave, 60Hz, resistive or inductive load.
For capacitance load, derate current by 20%.
Characteristic Symbol
Value
Unit
Peak Repetitive Reverse Voltage
Working Peak Reverse Voltage
DC Blocking Voltage
V
RRM
V
RWM
V
RM
60 V
Average Rectified Output Current
(Per Leg)
(Total)
I
O
15
30
A
Non-Repetitive Peak Forward Surge Current 8.3ms
Single Half Sine-Wave Superimposed on Rated Load
I
FSM
200 A
Thermal Characteristics
(Per Leg)
Characteristic Symbol
Value
Unit
Maximum Thermal Resistance Junction to Case
R
θJC
2 °C/W
Operating and Storage Temperature Range
T
J
, T
STG
-65 to +150
°C
Electrical Characteristics (Per Leg)
@T
A
= 25°C unless otherwise specified
Characteristic Symbol
Min
Typ
Max
Unit
Test
Condition
Forward Voltage Drop (per leg)
V
F
-
0.56
-
0.62
0.60
V
I
F
= 15A, T
J
= +25°C
I
F
= 15A, T
J
= +125°C
Leakage Current (Note 4)
I
R
-
0.125
-
0.5
45
mA
V
R
= 60V, T
J
= +25°C
V
R
= 60V, T
J
= +125°C
Notes:
4. Short duration pulse test used to minimize self-heating effect.
0
100
200
300
400
500
600
700
Fig. 1 Typical Forward Characteristics
V , INSTANTANEOUS FORWARD VOLTAGE (mV)
F
0.001
0.01
0.1
1
10
100
I
, IN
S
TAN
TANE
O
U
S
F
O
R
WA
R
D
C
U
R
R
EN
T
(A
)
F
1
100
10,000
0
10
20
30
40
50
60
Fig. 2 Typical Reverse Characteristics
V , INSTANTANEOUS REVERSE VOLTAGE (V)
R
I
, INST
A
N
TA
NEOUS
REVE
RSE
CURRE
NT
(
µ
A)
R
