Page 5
SBR is a registered trademark of Diodes Incorporated.
SBR20A300
Document number: DS30993 Rev. 8 - 2
5 of 6
January 2014
© Diodes Incorporated
SBR20A300CT
SBR20A300CTB
SBR20A300CTFP
A
A1
c
D
E
L
b
e1
b2
P
H1
Q
L1
A2
e
SE
A
T
IN
G
P
LA
N
E
D1
16.
00
0.
20*
*Guaranteed by TO-220AB leadframe design
E
D
b2
b
e
c2
A
H
See Detail B
7°±1°
c
E1
D1
A1
Gauge Plane
L
L3
a
Detail B
Seating
Plane
L2
L1
1
2
K
Package Outline Dimensions
(Cont.)
rsion.
TO-220AB
Dim Min Typ
Max
A
3.56
- 4.82
A1 0.51
- 1.39
A2 2.04
- 2.92
b
0.39 0.81 1.01
b2 1.15 1.24 1.77
c 0.356
- 0.61
D 14.22
- 16.51
D1 8.39
- 9.01
e
2.54
e1
5.08
E
9.66
- 10.66
H1 5.85
- 6.85
L 12.70
- 14.73
L1
- -
6.35
P
3.54
- 4.08
Q
2.54
- 3.42
All Dimensions in mm
TO263
Dim Min Max
A
4.07 4.82
A1
0.00 0.25
b
0.51 0.99
b2
1.15 1.77
c
0.356 0.73
c2
1.143 1.65
D
8.39 9.65
D1
6.55
E
9.66 10.66
E1
6.23
e
2.54 Typ
H
14.61 15.87
L
1.78 2.79
L1
1.67
L2
1.77
a
0° 8°
All Dimensions in mm
