SBR20A200CTB
Document number: DS31076 Rev. 7 - 2
2 of 4
July 2011
© Diodes Incorporated
SBR20A200CTB
SBR is a registered trademark of Diodes Incorporated.
Maximum Ratings
@T
A
= 25°C unless otherwise specified
Single phase, half wave, 60Hz, resistive or inductive load.
For capacitance load, derate current by 20%.
Characteristic Symbol
Value
Unit
Peak Repetitive Reverse Voltage
Working Peak Reverse Voltage
DC Blocking Voltage
V
RRM
V
RWM
V
RM
200 V
Average Rectified Output Current @ T
C
= 150ºC
I
O
20 A
Non-Repetitive Peak Forward Surge Current 8.3ms
Single Half Sine-Wave Superimposed on Rated Load
I
FSM
180 A
Thermal Characteristics
Characteristic Symbol
Value
Unit
Maximum Thermal Resistance (per leg)
Thermal Resistance Junction to Case (Note 4)
Thermal Resistance, Junction to Ambient (Note 4)
R
θJC
R
θJA
4
43
ºC/W
Operating and Storage Temperature Range
T
J
, T
STG
-65 to +175
ºC
Electrical Characteristics
@T
A
= 25°C unless otherwise specified
Characteristic Symbol
Min
Typ
Max
Unit
Test
Condition
Forward Voltage Drop
V
F
-
-
-
0.66
0.86
0.96
0.72
V
I
F
= 10A, T
J
= 25ºC
I
F
= 20A, T
J
= 25ºC
I
F
= 10A, T
J
= 125ºC
Leakage Current (Note 5)
I
R
-
0.003
0.51
0.1
10
mA
V
R
= 200V, T
J
= 25ºC
V
R
= 200V, T
J
= 125ºC
Reverse Recovery Time
t
rr
- 24 30
ns
I
F
= 0.5A, I
R
= 1A, I
RR
= 0.25A
- 20 25
I
F
= 1A, V
R
= 30V,
di/dt = 100A/
μs, T
J
= 25ºC
Notes:
4. FR-4 PCB, 2 oz. Copper, minimum recommended pad lay5. Short duration pulse test used to minimize self-heating effect.
T = -65°C
J
T = 25°C
J
T = 75°C
J
T = 125°C
J
T = 150°C
J
T = 175°C
J
T = 25°C
J
T = 75°C
J
T = 125°C
J
T = 150°C
J
T = 175°C
J
