SBR20A100CTE
Document number: DS31968 Rev. 2 - 2
3 of 4
www.diodes.com
November 2011
© Diodes Incorporated
SBR20A100CTE
SBR is a registered trademark of Diodes Incorporated.
0
5
10
0 25 50 75 100 125 150 175
T , CASE TEMPERATURE (°C)
C
Fig. 3 Forward Current Derating Curve, Per Element
I,
A
V
E
R
A
G
E F
O
R
WA
R
D
C
U
R
R
E
N
T
(A
)
F(
A
V
)
0
1
2
3
4
5
6
7
8
9
10
0 5 10 15 20
I , AVERAGE FORWARD CURRENT (A)
F(AV)
Fig. 4 Forward Power Dissipation
P
,
P
O
WE
R
DIS
S
IP
A
T
IO
N (
W
)
D
Package Outline Dimensions
TO262
Dim Min Max Typ
A 4.06 4.83 4.57
A2 2.03 2.79 2.67
b 0.64 0.99 -
b2 1.14 1.40 1.24
c 0.35 0.74 -
c2 1.14 1.40 1.27
D 8.64 9.65 8.70
E 9.65 10.29 10.11
e 2.54 Typ
L 12.70 14.73 13.60
L1 - 1.67 -
L2 − 4.00 -
All Dimensions in mm
E
D
L1
c2
A
L
b
b2
L2
e
A2
c
