SBR20A100CTE
Document number: DS31968 Rev. 2 - 2
2 of 4
www.diodes.com
November 2011
© Diodes Incorporated
SBR20A100CTE
SBR is a registered trademark of Diodes Incorporated.
Maximum Ratings (Per Leg)
@T
A
= 25°C unless otherwise specified
Single phase, half wave, 60Hz, resistive or inductive load.
For capacitance load, derate current by 20%.
Characteristic Symbol Value Unit
Peak Repetitive Reverse Voltage
Working Peak Reverse Voltage
DC Blocking Voltage V RRM
V
RWM
V
RM
100 V
Average Rectified Output Current Per Device (Per Leg)
(Total)
I O
10
20
A
Non-Repetitive Peak Forward Surge Current 8.3ms
Single Half Sine-Wave Superimposed on Rated Load
I
FSM
250 A
Thermal Characteristics (Per Leg)
Characteristic Symbol Value Unit
Maximum Thermal Resistance, Junction to Case R θJC 2 ºC/W
Operating and Storage Temperature Range T
J
, T
STG
-65 to +175 ºC
Electrical Characteristics (Per Leg)
@T
A
= 25°C unless otherwise specified
Characteristic Symbol Min Typ Max Unit Test Condition
Forward Voltage Drop V
F
-
-
0.60
0.75
0.64
V
I
F
= 10A, T
J
= 25ºC
I
F
= 10A, T
J
= 125ºC
Leakage Current (Note 4) I
R
- -
0.1
10
mA
V
R
= 100V, T
J
= 25ºC
V
R
= 100V, T
J
= 125ºC
Notes: 4. Short duration pulse test used to minimize self-heating effect.
0.001
0.1
1
10
100
I,
I
N
S
T
A
N
T
A
N
E
O
U
S
F
O
R
WA
R
D
C
U
R
R
E
N
T
(A
)
F
0.01
0 0.2 0.4 0.6 0.8 1.0
V , INSTANTANEOUS FORWARD VOLTAGE (V)
F
Fig. 1 Typical Forward Characteristics
T = 85°C
A
T = 150°C
A
T = 175°C
A
T = 25°C
A
T = 125°C
A
I
, INS
T
ANT
A
NEOU
S
REVE
RSE C
URRENT
(
µA
)
R
0 20 40 60 80 100
V , INSTANTANEOUS REVERSE VOLTAGE (V)
R
Fig. 2 Typical Reverse Characteristics
T = 25°C
A
T = 85°C
A
T = 125°C
A
T = 150°C
A
T = 175°C
A
