SBR20100CTP
Document number: DS31762 Rev. 6 - 2
2 of 4
December 2010
© Diodes Incorporated
SBR20100CTP
SBR is a registered trademark of Diodes Incorporated.
Maximum Ratings (Per Leg)
@T
A
= 25°C unless otherwise specified
Single phase, half wave, 60Hz, resistive or inductive load.
For capacitance load, derate current by 20%.
Characteristic Symbol
Value
Unit
Peak Repetitive Reverse Voltage
Working Peak Reverse Voltage
DC Blocking Voltage
V
RRM
V
RWM
V
RM
100 V
Average Rectified Output Current per Device
(Per Leg)
(Total)
I
O
10
20
A
Non-Repetitive Peak Forward Surge Current 8.3ms
Single Half Sine-Wave Superimposed on Rated Load
I
FSM
150 A
Isolation Voltage
From terminal to heatsink t = 1 min.
V
AC
4000 V
Thermal Characteristics (Per Leg)
Characteristic Symbol
Value
Unit
Typical Thermal Resistance
R
θJC
3 ºC/W
Operating and Storage Temperature Range
T
J
, T
STG
-65 to +175
ºC
Electrical Characteristics (Per Leg)
@T
A
= 25°C unless otherwise specified
Characteristic Symbol
Min
Typ
Max
Unit
Test
Condition
Forward Voltage Drop
V
F
-
-
-
0.82
0.75
V
I
F
= 10A, T
J
= 25ºC
I
F
= 10A, T
J
= 125ºC
Leakage Current (Note 2)
I
R
-
-
-
-
100
10
μA
mA
V
R
= 100V, T
J
= 25ºC
V
R
= 100V, T
J
= 125ºC
Notes:
2. Short duration pulse test used to minimize self-heating effect.
Fig. 1 Forward Power Dissipation
0
1
2
3
4
5
6
7
8
9
0
5
10
15
I
, AVERAGE FORWARD CURRENT (A)
F(AV)
P
,
P
O
WE
R
DISS
IP
A
T
IO
N (
W
)
D
T = 175°C
J
0
200
400
600
800
1,000
Fig. 2 Typical Forward Characteristics
V , INSTANTANEOUS FORWARD VOLTAGE (mV)
F
0.0001
0.001
0.01
0.1
1
10
100
I,
I
N
S
T
AN
T
AN
E
O
U
S
F
O
R
WA
R
D
C
U
R
R
EN
T
(A
)
F
T = 25°C
A
T = 85°C
A
T = 125°C
A
T = 150°C
A
