SBR1U30CSP
Document number: DS36110 Rev. 2 - 2
2 of 4
November 2013
© Diodes Incorporated
SBR1U30CSP
NEW PROD
UC
T
Maximum Ratings
(@T
A
= +25°C, unless otherwise specified.)
Single phase, half wave, 60Hz, resistive or inductive load.
For capacitance load, derate current by 20%.
Characteristic Symbol
Value
Unit
Peak Repetitive Reverse Voltage
V
RRM
30 V
Average Rectified Output Current
I
O
1 A
Non-Repetitive Peak Forward Surge Current 8.3ms
Single Half Sine-Wave Superimposed on Rated Load
I
FSM
12 A
Thermal Characteristics
Characteristic Symbol
Value
Unit
Typical Thermal Resistance Junction to Ambient (Note 5)
R
θJA
140 °C/W
Operating and Storage Temperature Range
T
J
, T
STG
-55 to +150
°C
Electrical Characteristics
(@T
A
= +25°C, unless otherwise specified.)
Characteristic Symbol
Min
Typ
Max
Unit
Test
Condition
Forward Voltage Drop
V
F
— — 0.42
V
I
F
= 0.5A
— — 0.48
I
F
= 1 A
— 0.41 —
I
F
= 1 A, T
J
= +125°C
Reverse Current (Note 6)
I
R
— 6 15
µA
V
R
= 10V
— 10 75
V
R
= 30V
Junction Capacitance
C
j
— 80 — pF
V
R
= 4V, f = 1MHz
Notes:
5. Device mounted on FR-4 PCB, 2oz. Copper, minimum recommended pad lay
6. Short duration pulse test used to minimize self-heating effect.
Figure 1 Typical Forward Characteristics
V , INSTANTANEOUS FORWARD VOLTAGE (V)
F
I
, I
N
ST
ANT
A
NE
OUS F
O
R
W
A
RD C
URRE
NT
(
A
)
F
0.0001
0.001
0.01
T = 25°C
A
0.1
T = 85°C
A
1
T = 125°C
A
0
T = 150°C
A
100
200
300
400
500
T = -55°C
A
I
,
IN
ST
ANT
A
NEO
U
S RE
VERSE
CUR
R
E
N
T
(
µ
A)
R
V , INSTANTANEOUS REVERSE VOLTAGE (V)
R
Figure 2 Typical Reverse Characteristics
0.01
0.1
1
10
100
1000
10000
100000
0
5
10
15
20
25
30
T = 25°C
A
T = 85°C
A
T = 125°C
A
T = 150°C
A
T = -55°C
A
