SBR1U150SA
Maximum Ratings
(@T
A
= +25°C, unless otherwise specified.)
Single phase, half wave, 60Hz, resistive or inductive load.
For capacitance load, derate current by 20%.
Characteristic Symbol
Value
Unit
Peak Repetitive Reverse Voltage
Working Peak Reverse Voltage
DC Blocking Voltage
V
RRM
V
RWM
V
RM
150 V
RMS Reverse Voltage
V
R(RMS)
106 V
Average Rectified Output Current (See Figure 1)
I
O
1.0 A
Non-Repetitive Peak Forward Surge Current 8.3ms
Single Half Sine-Wave Superimposed on Rated Load
I
FSM
42 A
Repetitive Peak Avalanche Power (1
μS, +25°C)
P
ARM
6,000 W
Thermal Characteristics
Characteristic Symbol
Value
Unit
Thermal Resistance Junction to Soldering (Note 6)
R
θJS
3
°C/W
Thermal Resistance Junction to Ambient (Note 7)
R
θJA
119
Thermal Resistance Junction to Ambient (Note 8)
R
θJA
88
Operating and Storage Temperature Range
T
J
, T
STG
-65 to +150
°C
Electrical Characteristics
(@T
A
= +25°C, unless otherwise specified.)
Characteristic Symbol
Min
Typ
Max
Unit
Test
Condition
Reverse Breakdown Voltage (Note 9)
V
(BR)R
150 - - V
I
R
= 100µA
Forward Voltage Drop
V
F
- -
0.70
V
I
F
= 1.0A, T
J
= +25ºC
- -
0.56
I
F
= 1.0A, T
J
= +125ºC
Leakage Current (Note 9)
I
R
- -
0.1
mA
V
R
= 150V, T
J
= +25ºC
- -
10
mA
V
R
= 150V, T
J
= +125ºC
Notes:
6. Theoretical R
θJS
calculated from the top center of the die straight down to the PCB cathode tab solder junction.
7. FR-4 PCB, 2 oz. Copper, minimum recommended pad lay
A
= 25ºC
8. Polymide PCB, 2 oz. Copper, minimum recommended pad layout pe
9. Short duration pulse test used to minimize self-heating effect.
