Diodes SBR130S3 - Manual (Page 2)

SBR is a registered trademark of Diodes Incorporated.
SBR130S3
Document number: DS31099 Rev. 6 - 2
2 of 4
www.diodes.com
April 2012
© Diodes Incorporated
SBR130S3
NEW PROD
UC
T
Maximum Ratings
@T
A
= 25°C unless otherwise specified
Single phase, half wave, 60Hz, resistive or inductive load.
For capacitance load, derate current by 20%.
Characteristic Symbol Value Unit
Peak Repetitive Reverse Voltage
Working Peak Reverse Voltage
DC Blocking Voltage V
RRM
V
RWM
V
RM
30 V
RMS Reverse Voltage V R(RMS)
21 V
Average Rectified Output Current T
C
= 65°C I
O
1 A
Non-Repetitive Peak Forward Surge Current
8.3ms Single Half Sine-Wave Superimposed on Rated Load
I
FSM
20 A
Thermal Characteristics
Characteristic Symbol Value Unit
Maximum Thermal Resistance
Thermal Resistance Junction to Ambient (Note 5)
R θJA 488 ºC/W
Operating and Storage Temperature Range T
J
, T
STG
-65 to +150 ºC
Electrical Characteristics
@T
A
= 25°C unless otherwise specified
Characteristic Symbol Min Typ Max Unit Test Condition
Reverse Breakdown Voltage (Note 6) V
(BR)R
30 - - V I
R
= 200µA
Forward Voltage Drop V
F
- 0.39 0.43
V
I
F
= 700mA, T
J
= 25ºC
- 0.31 0.34 I
F
= 700mA, T
J
= 150ºC
- 0.42 0.46 I F = 1A, T J = 25ºC
- 0.36 0.39 I
F
= 1A, T
J
= 150ºC
Leakage Current (Note 6) I
R
- 8.0 20 µA V
R
= 10V, T
J
= 25ºC
- 4.0 10 mA V R = 10V, T J = 150ºC
- 12 50 µA V
R
= 30V, T
J
= 25ºC
- 5 15 mA V
R
= 30V, T
J
= 150ºC
Notes: 5. FR-4 PCB, 2 oz. Copper, minimum recommended pad layout per http://www.diodes.com.
6. Short duration pulse test used to minimize self-heating effect.
T = -55°C
A
T = 25°C
A
T = 75°C
A
T = 125°C
A
T = 150°C
A
T = -55°C
A
T = 25°C
A
T = 75°C
A
T = 125°C
A
T = 150°C
A
