SBR10U45SP5


10A SBR

®

SUPER BARRIER RECTIFIER

POWERDI

®

Features

Designed as Bypass Diodes for Solar Panels

Selectively Rated for 200°C Maximum Junction Temperature for

High Thermal Reliability

Patented Super Barrier Rectifier Technology

High Forward Surge Capability

Ultra Low Forward Voltage Drop

Excellent High Temperature Stability

Totally Lead-Free & Fully RoHS Compliant (Notes 1 & 2)

Halogen and Antimony Free. “Green” Device (Note 3)

Mechanical Data

 Case:

POWERDI5

Case Material: Molded Plastic, “Green” Molding Compound.

UL Flammability Classification Rating 94V-0

Moisture Sensitivity: Level 1 per J-STD-020

Terminals: Finish – Matte Tin annealed over Copper leadframe.

Solderable per MIL-STD-202, Method 208

Weight: 0.093 grams (approximate)

Ordering Information

(Note 4)

Part Number

Case

Packaging

SBR10U45SP5-13

POWERDI5

5000/Tape & Reel

SBR10U45SP5-7

POWERDI5

1500/Tape & Reel

Notes:

1. No purposely added lead. Fully EU Directive 2002/95/EC (RoHS) & 2011/65/EU (RoHS 2) compliant.

2. See http://www.diodes.com/quality/lead_free.html for more information about Diodes Incorporated’s definitions of Halogen- and Antimony-free, "Green"

and Lead-free.

3. Halogen- and Antimony-free "Green” products are defined as those which contain <900ppm bromine, <900ppm chlorine (<1500ppm total Br + Cl) and

<1000ppm antimony compounds.

4. For packaging details, go to our website at http”//www.diodes.com/products/packages.html.





Marking Information










Top View

Bottom View

LEFT PIN

RIGHT PIN

Note: Pins Left & Right must
be electrically connected

at the printed circuit board.

BOTTOMSIDE
HEAT SINK

S10U45S = Product Type Marking Code

= Manufacturers’ Code Marking

K = Factory Designator
YYWW = Date Code Marking
YY = Last Two Digits of Year (ex: 13 for 2013)
WW = Week code (01 - 53)

YYWWK

S10U45S

POWERDI5
