SBR05M60BLP
Document number: DS31771 Rev. 2 - 2
3 of 4
June 2010
© Diodes Incorporated
SBR05M60BLP
SBR is a registered trademark of Diodes Incorporated.
Ordering Information
(Note 5)
Part Number
Case
Packaging
SBR05M60BLP-7
DFN3030-4
3000/Tape & Reel
Notes:
5. For packaging details, go to our website at
Marking Information
Date Code Key
Year
2009
2010
2011
2012
2013 2014 2015
Code
W X Y Z A B C
Month
Jan
Feb
Mar
Apr
May
Jun
Jul
Aug
Sep
Oct
Nov
Dec
Code 1 2 3 4 5 6 7 8 9 O N D
Package Outline Dimensions
DFN3030-4
Dim
Min
Max Typ
A
0.57
0.63 0.60
A1
0 0.05
0.02
A3
- -
0.15
b
0.35
0.45 0.40
D
2.90
3.10 3.00
D1
1.075 1.275 1.175
D2
0.925 1.125 1.025
D3
1.075 1.275 1.175
E
2.90
3.10 3.00
e
- -
1.30
E1
0.615 0.815 0.715
E2
1.78
1.98 1.88
E3
0.715 0.915 0.815
H
0.05
0.15 0.10
I
0.20
0.30 0.25
J
0.185 0.285 0.235
K
0.065 0.165 0.115
L
0.30
0.60 0.45
M
0.05
0.15 0.10
Z
- -
0.65
All Dimensions in mm
5 6 = Product Type Marking Code
YM = Date Code Marking
Y = Year (ex: W = 2009)
M = Month (ex: 9 = September)
DFN3030-4
N/C
E
E3
D3
E2
D2
L
D
E1
D1
Side View
Bottom View
A1
A3
e
b
Z
H
M
I
K
A
J
