SBR05M60BLP

SBR is a registered trademark of Diodes Incorporated.


0.5A SBR

®

BRIDGE

SUPER BARRIER RECTIFIER

Features

Ultra Low Leakage Current

Excellent High Temperature Stability

Patented Super Barrier Rectifier Technology

Soft, Fast Switching Capability

150ºC Operating Junction Temperature

Lead Free Finish, RoHS Compliant (Note 1)

“Green” Device (Note 3)

Mechanical Data

• Case:

DFN3030-4

Case Material: Molded Plastic “Green” Molding Compound,
UL Flammability Classification Rating 94V-0

Moisture Sensitivity: Level 1 per J-STD-020

Terminals: Finish – NiPdAu Over Copper Lead Frame,

Solderable per MIL-STD-202, Method 208

Polarity: See Diagram

Marking Information: See Page 3

Ordering Information: See Page 3

Weight: 0.02 grams (approximate)
















Maximum Ratings

@T

A

= 25°C unless otherwise specified

Single phase, half wave, 60Hz, resistive or inductive load.
For capacitance load, derate current by 20%.

Characteristic Symbol

Value

Unit

Peak Repetitive Reverse Voltage
Working Peak Reverse Voltage
DC Blocking Voltage

V

RRM

V

RWM

V

RM

60 V

Average Rectified Output Current

I

O

500 mA

Non-Repetitive Peak Forward Surge Current 8.3ms
Single Half Sine-Wave Superimposed on Rated Load (Per Diode)

I

FSM

8 A


Thermal Characteristics

Characteristic Symbol

Typ

Max

Unit

Thermal Resistance Junction to Ambient Air (Note 2)

R

θJA

215 -

°C/W

Operating and Storage Temperature Range

T

J

, T

STG

-55 to +150

°C


Electrical Characteristics

@T

A

= 25°C unless otherwise specified

Characteristic Symbol

Min

Typ

Max

Unit

Test

Condition

Forward Voltage (Per Diode)

V

F

-

-

0.43
0.40

0.42
0.49
0.46

V

I

F

= 0.25A, T

J

= 25ºC

I

F

= 0.5A, T

J

= 25ºC

I

F

= 0.5A, T

J

= 125ºC

Reverse Current (Note 4) (Per Diode)

I

R

-

17

2.8

100

20

µA

mA

V

R

= 60V, T

J

= 25ºC

V

R

= 60V, T

J

= 125ºC

Notes:

1. EU Directive 2002/95/EC (RoHS). All applicable RoHS exemptions applied, see EU Directive 2002/95/EC Annex Notes.
2. Polymide PCB, 2 oz. copper; minimum recommended pad layout per http://www.diodes.com/datasheets/ap02001.pdf.
3. Diodes Inc.’s “Green” policy can be found on our website at http://www.diodes.com/products/lead_free/index.php

4. Short duration pulse test used to minimize self-heating effect.



Top View

Device Schematic

Top View

Pin Configuration

2

1

3

4

1

2

4

3

N/C
