SBR10100CTL
Document number: DS31206 Rev. 3 - 2
2 of 4
December 2011
© Diodes Incorporated
SBR10100CTL
NEW PROD
UC
T
SBR is a registered trademark of Diodes Incorporated
Maximum Ratings (Per Leg)
@T
A
= 25°C unless otherwise specified
Single phase, half wave, 60Hz, resistive or inductive load.
For capacitance load, derate current by 20%.
Characteristic Symbol
Value
Unit
Peak Repetitive Reverse Voltage
Working Peak Reverse Voltage
DC Blocking Voltage
V
RRM
V
RWM
V
RM
100 V
RMS Reverse Voltage
V
R(RMS)
71 V
Average Rectified Output Current Per Device
I
O
10 A
Non-Repetitive Peak Forward Surge Current 8.3ms
Single Half Sine-Wave Superimposed on Rated Load
I
FSM
110 A
Thermal Characteristics (Per Leg)
Characteristic Symbol
Value
Unit
Typical Thermal Resistance (Note 4)
R
θJC
22 ºC/W
Operating and Storage Temperature Range
T
J
, T
STG
-65 to +175
ºC
Electrical Characteristics (Per Leg)
@T
A
= 25°C unless otherwise specified
Characteristic Symbol
Min
Typ
Max
Unit
Test
Condition
Forward Voltage Drop
V
F
-
-
0.77
0.63
0.84
0.71
V
I
F
= 5A, T
J
= 25ºC
I
F
= 5A, T
J
= 125ºC
Leakage Current (Note 3)
I
R
-
-
-
-
0.2
25
mA
V
R
= 100V, T
J
= 25ºC
V
R
= 100V, T
J
= 125ºC
Notes:
3. Short duration pulse test used to minimize self-heating effect
4. Device mounted on FR-4 substrate PC board, 1oz copper .with minimum recommended pad layout.
5. Device mounted on Polymide substate, 1*MRP, 2oz, copper, PC boards.
0
0
1
2
3
4
5
I
AVERAGE FORWARD CURRENT (A)
Fig. 1 Forward Power Dissipation
F(AV)
P
,
P
O
WE
R
DI
SSI
P
A
T
IO
N
(W
)
D
0.5
1.0
1.5
2.0
2.5
0.001
0
0.1
0.2
0.3
0.4
0.5
0.6
0.7
0.8 0.9
I,
I
N
S
T
AN
T
ANE
O
U
S F
O
R
WA
R
D
C
U
R
R
EN
T
(A
)
F
Fig. 2 Typical Forward Characteristics
V , INSTANTANEOUS FORWARD VOLTAGE (V)
F
0.01
0.1
1
10
100
T = 25°C
A
T = 85°C
A
T = 125°C
A
T = 150°C
A
T = 175°C
A
