152.765UK User Manual
DMX parameters continued
Channel Parameter Value Function
CH10 X-axis roll
000-127 0 -359 degree fixed X axis rolled
128-191 Clockwise rolling
192-255 Anticlockwise rolling
CH11 X-axis roll speed 000-255 Roll speed: fast to slow
CH12 Z-axis roll
000-127 0 -359 degree fixed X axis rolled
128-191 Clockwise rolling
192-255 Anticlockwise rolling
CH13 Z-axis roll speed 000-255 Roll speed: fast to slow
CH14
Y-axis transit
000-127 128 fixed positions on Y-axis
128-191 Left to right transit
192-255 Right to left transit
CH15 Y-axis transit speed 000-255 Transit speed: fast to slow
CH14
X-axis transit
000-127 128 fixed positions on X-axis
128-191 Left to right transit
192-255 Right to left transit
CH15 X-axis transit speed 000-255 Transit speed: fast to slow
