152.765UK User Manual
DMX parameters
Channel Parameter Value Function
CH1 Mode
000-020 Laser off
021-040 Auto mode fast
041-100 Auto mode slow
101-120 Sound activated mode fast
121-180 Sound activated mode slow
181-200 Auto mode pattern effect
201-220 Sound activated mode pattern effect
221-255 DMX mode
CH2 Pattern Group
000-051 Group 1 patterns
052-103 Group 2 patterns
104-155 Group 3 patterns
156-207 Group 4 patterns
208-255 Group 5 patterns
CH3 Pattern select 000-255 Step through 16 patterns for each group (80
total)
CH4 Colour select
000-007 Multi-colour (pre-programmed)
008-015 Red
016-023 Green
024-031 Yellow
032-039 Blue
040-047 Purple
048-055 Light blue
056-063 White
064-111 Colour rolling
112-159 Colour jump
160-207 Colour moving
208-255 Strobing
001-127 0%-99% pattern clipped
128-255 Clipping speed
CH6 Zoom
000-127 100%-5% pattern zoom
128-169 Zooming in
170-209 Zooming out
210-255 Alternate zooming in and out
CH7 Zoom speed 000-255 Zooming effect speed: fast to slow
CH8 Y-axis roll
000-127 0 -359 degree fixed Y axis rolled
128-191 Clockwise rolling
192-255 Anticlockwise rolling
CH9 Y-axis roll speed 000-255 Roll speed: fast to slow
