152.765UK User Manual
Control panel options
Display Mode Press ENTER for setting (press FUNC to exit)
 /  Auto or Sound mode
 = auto sequence through patterns 
 = sound-activated sequence through patterns 
 Microphone sensitivity  (minimum) to  (maximum)
 DMX start address  to 
 Slave mode   = direct slave mode (mimics master unit) 
 Remote mode  = handheld IR remote controlled
 Invert mode Select normal, flip vertical, flip horizontal or both
Stand-alone modes
THE WORM laser can operate in stand-alone mode one of 2 ways: Auto or Sound-activated
 Press the FUNC button and navigate until  or  is displayed
 Press UP or DOWN to toggle between auto and sound-activated modes
 Press ENTER to confirm the required mode
Microphone sensitivity
In sound-activated mode, the sensitivity of the internal microphone can be adjusted via the
control panel. To set the sensitivity level, do the following…
 Press the FUNC button and navigate until  is displayed
 Press ENTER and 10 levels are available using the UP and DOWN buttons
o  = lowest sensitivity,  = highest sensitivity
 Press ENTER to confirm the required sensitivity level
Master/Slave mode
One or more THE WORM lasers can be operated simultaneously in slave mode from a master
unit operating in auto or sound-activated mode.
To set up a master/slave chain, connect a DMX lead from the DMX output of the master unit
and connect to the DMX input of the slave unit. Further slave units can be connected from the
first slave unit via DMX in the same manner.
To enable slave mode on the unit(s) to be controlled, press the FUNC button until
 is
displayed. The slave mode is only active when a master signal is received via DMX.
