8
the polarity markings on the unit’s body. Screw the battery compartment cap back into position.
To turn the IR illuminator on, rotate the operation switch from the OFF position.
To adjust the power and brightness of the beam emitted by the IR illuminator, rotate the illuminator
operation switch.
Focus the IR beam to change the field of coverage. To focus the beam, rotate the IR illuminator lens until
the image becomes clear.
Adjust the IR spot position in the field of view of the Spark-X as follows:
1) Loosen the screw of the clamp on the IR illuminator mount.
2) Turn on the night vision device and the IR illuminator.
3) Carefully move the lens of the IR illuminator up and down and side to side. While looking through
the eyepieces of your device, observe the IR spot position.
4) Tighten the fixing screw of the clamp once the IR spot is centered in the field of view.
4. MAINTENANCE PROCEDURES
The Spark-X should always be stored in the supplied packaging, particularly in heated and ventilated
rooms. To keep the device operational, please follow the instructions listed previously regarding prep-
arations for storage. The battery should be stored separately from the device and be inserted into the
battery compartment only when the device is being prepared for use. The presence of both acids and
alkalis near the goggles is not recommended.
When stored, your Spark-X should be protected from exposure to direct sunlight or extreme tempera-
tures.
GOGGLES CLEANING PROCEDURES
1) Gently remove any dirt from the goggles using a clean, soft cloth.
2) Wipe external surfaces down (with the exception of optical surfaces) with a clean cloth moistened
with pure water.
3) Dry all wet surfaces with a different clean, dry cloth.
4) Carefully remove any dirt from the optical surfaces using a lens brush.
5) To avoid scratches, optical surfaces must be cleaned using a clean cotton swab that has been slight-
ly dampened with pure alcohol. The glass should be wiped in circular motions starting from the center
and moving out towards the edge, without touching the barrel. Change the cotton swab as soon as it
becomes dirty.
PREPARATION FOR STORAGE
When preparing your Spark-X for storage, perform the following steps:
1) Verify that the goggles are operating in accordance with all previously specified procedures.
2) Remove the battery from the battery compartment.
3) Clean the goggles and all accessories.
4) Place all components into the storage case.
5. TROUBLESHOOTING
Common problems that may occur with your goggles or the detection and viewing tests, as well as ac-
tions you can take to correct them, are listed in the Troubleshooting Table below. This table does not
list all of the malfunctions that may occur with your device. If you experience a malfunction of the
device that is not listed in this table, please contact Armasight or your Spark-X retailer.
