4

STANDARD COMPONENTS AND OPTIONAL EqUIPMENT

1) Armasight Spark-X Goggles

Night vision goggles with 1x magnification.

2) Objective Lens Caps

The Objective Lens Caps are designed to protect the objective lens from physical damage, as well as

allow the testing of the device’s operation in daylight.

3) Eye Cups

The rubber eye cups are designed to protect the eyepieces and to provide comfortable use.

4) CR123A Lithium Battery

3V CR123A lithium batteries are used to supply power to the unit.

5) Head Mount

Adjustable universal assembly that secures the goggles to the user’s head, providing hands-free opera-

tion.

6) User Manual

The user manual contains a full description of the device and accessories, information about controls,

installation, maintenance and troubleshooting procedures.

7) Carrying Case

The carrying case is used to store and carry the Spark-X goggles and accessories.

8) Optional Helmet Mount (Part# ANHM000002)

Extra long-range infrared illuminator. Provides greater viewing capabilities when the environment has

little or no ambient light. Completed with Dovetail to Weaver Transfer Piece that allows the IR illumina-

tor to be mounted on the Spark-X.

9) Optional IR810 Detachable Long Range Infrared Illuminator with Dovetail to Weaver Transfer

Piece #21 (Part# ANKI000016)

Long-range infrared (IR) illuminator. Provides greater viewing capabilities when the environment has

little or no ambient light. Completed with Dovetail to Weaver Transfer Piece that allows the IR illumina-

tor to be mounted on the Spark-X.

10) Optional IR810W Detachable Wide Angle Adjustable X-Long Range Infrared Illuminator with

Dovetail to Weaver Transfer Piece #21 (Part# ANKIW00016)

A detachable LED extra-long-range IR illuminator with a wide, adjustable beam angle (2°-30°). Should

be used when there is little to no ambient light. Completed with Dovetail to Weaver Transfer Piece that

allows the IR illuminator to be mounted on the Spark-X.

2. PREPARATIONS FOR OPERATION

CAUTION

:

the spark-x night vision goggles are designed for several years of reliable service. to ensure

trouble-free performance, please observe the following instructions:
• Do not activate the device in daylight unless the protective lens covers are fitted securely

over the lenses. If the device is ON, do not direct the device at bright light sources, such as car

headlights, camp fires, street lights, etc., as this will cause damage to the device.
• Do not check the device operation in daylight unless the front lens caps are fitted securely

over the lenses, and even then, the device should only be ON for the few seconds it takes to

establish correct operation.
• Do not open the body of the device or otherwise disassemble it.
• Avoid dropping or otherwise impacting the device.
