Advanced Instruments, Inc.

32

Symptom

Possible Cause

Recommended Action

Response time slow

Air leak, dead legs, distance
of sample line, low flow rate,
high volume of optional filters
and scrubbers

Leak test entire sample system, reduce
dead volume or increase flow rate

H

2

S read

ing doesn’t

agree to expected
values

Pressure and temperature of
the sample is different than
span gas

Error in calibration

Abnormality in gas

Calibrate the transmitter (calibrate at
pressure and temperature similar to that of
sample)

Repeat calibration

Qualify the integrity of the sample gas (use
a portable analyzer as a secondary check)

Erratic H

2

Sreading

or

No H

2

S reading

Sudden Changes in sample
pressure

Loose sensor cable and or
sensor PCB

Incorrect polarity of ribbon
cable

Corroded sensor PCB

Liquid covering sensing area

Sensor nearing end of life

Calibrate the transmitter (calibrate at
pressure and temperature similar to that of
sample)

Maintain sample pressure to within
recommended range

Secure ribbon cable firmly by fully inserting
the ribbon cable into its mating socket on
the sensor PCB

Ensure that sensor PCB is firmly secured
on sensor

Ensure that the conductors of ribbon cable
align with COND on sensor PCB

Replace sensor PCB

Replace sensor

.

Replace sensor

Cannot span
calibrate

Cannot zero
calibrate

Incorrect span gas

Span gas pressure too high

Span flow rate too high

Incorrect sensor

Sensor nearing end of life

Zero offset outside of
recommended range

High sample/zero gas flow
causing back pressure on
sensor

Defective sensor

Check span gas with a secondary analyzer

Set span gas pressure within
recommended range

Set flow rate within recommended range

Replace sensor

Allow enough time for sensor to settle with
zero gas

Set sample/zero gas flow within
recommended range

Replace sensor
