Air Suspension C-2546 REV 7 User Manual
Page 7
7
C-2546RR REV 7 04/28/2014
EBM INSTALLATION:
PARTS LIST
P/N
QTY
DESCRIPTION
21-5226
1
EBM
29-5138 1 FUSE 5 AMP
FIGURE A FIGURE B
1.0
Locate and remove the spare tire under the rear of the truck.
2.0
Locate suspension module above spare tire corner bracket. Release clip
attaching wire harness to module. Figure A & B.
