Congratulations on your purchase of an Arnott air suspension product. We at Arnott
Incorporated are proud to offer a high quality product at the industry’s most competitive pricing.
Thank you for your confidence in us and our product.
Proper installation is essential to experience and appreciate the benefits of this system. Please
take a moment to review these installation instructions before you begin to install these
components on your vehicle.
It is equally important to be aware of all necessary safety measures while installing your new Air
Ride Suspension. This includes proper lifting and immobilizing of the vehicle and isolation of any
stored energy to prevent personal injury or property damage
“Engineered to Ride, Built to last”
WARNING: The air suspension system is under pressure (up to 10 bar, or
150 lbf/in ) verify pressure has been relieved and disconnect power to the air ride system
prior to disassembly. Do not allow dirt or grease to enter the system. Always wear
standard protective hand, ear, and eye protection when servicing the air
suspension system.
KIT CONTAINS:
PARTS LIST
P/N QTY DESCRIPTION
29-5009 2 SHOCK ABSORBERS, FRONT
21-5126 2 SHOCK ABSORBERS, REAR
14-3936 2 REAR COIL SPRINGS
21-6369 1 ACCESSORY KIT
