ASUS M3N78 SE 2-13
Processor Frequency Multiplier [Auto]
Allows you to set the processor frequency multiplier. Configuration options: [Auto] [x4.0
800MHz] [x5.0 1000MHz] [x6.0 1200MHz] [x7.0 1400MHz] [x8.0 1600MHz] [x9.0 1800MHz]
Processor Voltage [Standard]
Allows you to set the processor voltage. Configuration options: [Power Saving Mode]
[Standard] [+50mv] [+100mv]
Hyper Transport Speed [Auto]
Allows you to set the HyperTransport link speed. Configuration options: [200MHz] [400MHz]
[600MHz] [800 MHZ] [1 GHz] [Auto]
Hyper Transport Width [16 16 ]
Allows you to set the HyperTransport link width. Configuration options: [16 16 ] [8 8 ]
Memory Clock Mode [Auto]
Allows you to set the memory clock mode. Configuration options: [Auto] [Manual]
The following item appears only when the Memory Clock Mode item is set to [Manual].
Memclock Value [266MHz]
Allows you to set the memory clock value.
Configuration options: [266MHz] [333MHz] [400MHz] [533MHz]
DRAM Timing Mode [Auto]
Allows you to set the DRAM timing mode. Configuration options: [Auto] [DCT 0]
The following sub-items appear only when you set the DRAM Timing Mode item to [DCT 0].
CAS Latency (CL) [Auto]
Configuration options: [Auto] [3 CLK] [4 CLK] [5 CLK] [6 CLK] [7 CLK DH_Only]
TRCD [Auto]
Configuration options: [Auto] [3 CLK] [4 CLK] [5 CLK] [6 CLK]
tRTP [Auto]
[Auto] [2-4 CLK] [3-5 CLK]
The following item appears only when the CPU Overclocking item is set to [Manual].
CPU Frequency [200]
Allows you to set the CPU frequency. The valid value is from 200 MHz to 550 MHz.
The following item appears only when the CPU Overclocking item is set to [Overclock
Profile].
Overcloking Options [Auto]
Allows you to set the overclocking options.
Configuration options: [Auto] [Overclock 3%] [Overclock 5%] [Overclock 7%] [Test
mode]
