3-16 Chapter 3: BIOS setup
Chapter
3
The following two items appear only when you set the Ai Overclock Tuner item to
[Manual], [D.O.C.P.] or [X.M.P.].
BCLK Frequency [XXX]
Allows you to adjust the Internal Base Clock (BCLK). Use the <+> and <-> keys to adjust the
value. You can also type the desired value using the numeric keypad. The values range from
80 to 500.
PCIE Frequency [XXX]
Allows you to set the PCI Express frequency. Use the <+> and <-> keys to adjust the PCIE
frequency. The values range from 100 to 200.
3.5.6 DRAM Frequency [Auto]
Allows you to set the DDR3 operating frequency.
Configuration options: [Auto] [DDR3-800MHz] [DDR3-1066MHz] [DDR3-1333MHz]
[DDR3-1600*]
• The DRAM Frequency configuration options vary with the BCLK Frequency item
settings.
• According to Intel CPU spec, CPUs with a core frequency of 2.66G support the
maximum DIMM frequency of up to DDR3 1333. To use DIMMs of a higher frequency
with a 2.66G CPU, enable the
DRAM O.C. Profile feature in BIOS. Refer to section
3.5.1 Ai Overclock Tuner for details.
Selecting a very high DRAM frequency may cause the system to become unstable! If this
happens, revert to the default setting.
3.5.7 QPI Frequency [Auto]
Allows you to set the QuickPath Interconnect (QPI) frequency.
Configuration options: [Auto] [3200MHz] [3733MHz] [4800MHz] [5333MHz] [5867MHz]
[6400MHz]
3.5.8 DRAM Timing Control
The items in this menu allow you to set the DRAM timing control features.
The configuration options for some of the following items vary depending on the DIMMs
you install on the motherboard.
1st Information: 5-5-5-15-4-36-6-5-16
The values vary depending on your settings of the following sub-items:
DRAM CAS# Latency [Auto]
Configuration options: [Auto] [3 DRAM Clock] [4 DRAM Clock] – [10 DRAM Clock]
[11 DRAM Clock]
DRAM RAS# to CAS# Delay [Auto]
Configuration options: [Auto] [3 DRAM Clock] [4 DRAM Clock] – [14 DRAM Clock]
[15 DRAM Clock]
